WISE-2210-NA
LPWAN Self powered Sensor module(for CT)
Features
- Proprietary LPWAN (Sub-G) wireless technology with Less interference with high penetration rate capability
- Power over AI channel design, no extra power wired installation needed.
- High efficiency power charger design via CT (Current transformer, AC 0~100mA)
- Max. 3 AI channels for CT node
- Compact design, suitable for plug and play applications
Introduction
Power over CT with LPWAN technology are ideal for sustainable factory, building applications. Powered by maximum 3 CT (Current Transformer), no extra line cables or batteries
are required for switching or for collecting power current information such as pumps, servers, machine tools or presence detection. The private LPWAN network saves resources by
using fewer cables and eliminating the need for batteries.
Less interference with high penetration rate
LPWAN, created for machine-to-machine (M2M) and Internet of things (IoT) networks,
is not a single technology, but a variety of low-power, wide area network technologies.
Compare with traditional mobile network, LPWAN is known as lower cost with higher
power efficiency. WISE-2210 is the proprietary LPWAN which provides better connection
compare with traditional wireless technology.
Fast build-in your IoT applications
With Power over AI channel design, no wire power installation is needed. WISE-2210
is designing for fast build-in your IoT applications. As for the current transformer, we
support power current range from 3~60A to 15~300A for different current measurement
applications.
High efficiency power charger design
With Advantech’s strong hardware and software design capacity, WISE-2210 allows to
transmit the power current measurement data in seconds.
Specifications
Wireless Communication
Frequency Band:
NA: 923MHz (920.80~924.40)
EU: 868MHz (865.20~868.80)
JA: 923MHz (920.80~923.20)
Transmit Power: Up to +12dBm
Data Rate: 625bps / 2.5k bps / 5K bps / 50K bps
Topology: Star
General
Channel: 3 (for CT, 0-100mA, AC)
Input Range: 0-100mA, Alternating current
Resolution: 11 bits
Accuracy: ± 0.2 % of FSR
Drift: 40ppm
Power Input: Power source is from AI Channel
Configuration Interface: Micro-B USB
Mounting: DIN 35 rail, wall, pole
Dimension (W x H x D): 71 x 52 x 30 mm (without Antenna)
Certification: CE (RED), FCC, TELEC, NCC
Environment
Operating Temperature: -25~70 °C
Operating Humidity: 5~95% RH
Storage Temperature: -40~85 °C
Storage Humidity: 0~95% RH
